Dc To Ac Power Inverter Converter, 50W

The Pyle Plug in Car 50 Watt 12v DC to 115 Volt AC Power Inverter w/ Modified Sine Wave - Output Voltage: 100V-120V - Frequency: 60 +/- 2Hz Waveform: Modified Sine Wave - Input DC Voltage: 10-15 Volts - Under voltage Alarm: 10.4 - 11.0 Volts DC - Off Low pressure: 9.7 - 10.3 Volts DC - Shut Down Over- Voltage: 14.5 - 15.5 Volts Dc - No - Load Consumption: 12 Volts DC - No - Load Current: <0.3 Amps - Continuous Output Power: 50 Watts - Surge Peak Output Power: 100 Watts - Dimensions: 3.54''L x 3.14''W x 1.69''.

• Output Voltage: 100V-120V - Shut Down Over- Voltage: 14.5 - 15.5 Volts Dc - Dimensions: 3.54''L x 3.14''W x 1.69''
• Frequency: 60 +/- 2Hz Waveform: Modified Sine Wave - No - Load Consumption: 12 Volts DC
• Input DC Voltage: 10-15 Volts - No - Load Current: <0.3 Amps
• Under voltage Alarm: 10.4 - 11.0 Volts DC - Continuous Output Power: 50 Watts
• Off Low pressure: 9.7 - 10.3 Volts DC - Surge Peak Output Power: 100 Watts

Output Voltage: 100V-120V

Frequency: 60 +/- 2Hz Waveform: Modified Sine Wave

Input DC Voltage: 10-15 Volts

Under voltage Alarm: 10.4 - 11.0 Volts DC

Off Low pressure: 9.7 - 10.3 Volts DC

Shut Down Over- Voltage: 14.5 - 15.5 Volts Dc

No - Load Consumption: 12 Volts DC

No - Load Current: <0.3 Amps

Continuous Output Power: 50 Watts

Surge Peak Output Power: 100 Watts

Dimensions: 3.54''L x 3.14''W x 1.69''
